RHTemp1000

Compact Design

RHTemp1000 is a compact, humidity and temperature data logger. Includes ISO17025 accredited calibration certificate.

Availability: 5-7 Business Days

$429.00

Extended Warranty

Description

The RHTemp1000 is a compact, humidity and temperature data logger, ideal for use in harsh environments.

This device measures and records temperatures from -40 °C to +80 °C (-40 °F to +176 °F) with an accuracy of ±0.5 °C. The RHTemp1000 can store up to 16,384 time and date stamped readings, and is able to be programmed to start up to 24 months in advance.

The RHTemp1000 is compatible with the latest MadgeTech 4 Software making starting, stopping, and downloading simple and easy. Graphical, tabular, and summary data is provided for analysis and can be viewed as customizable engineering units.

General

Memory16,384 readings (all channels enabled)
Reading Rate1 reading every second up to 1 reading every 24 hours
Battery Life2 years typical at 25 °C, 15 minute reading intervals
Material316 Stainless Steel/Radel
Dimensions1.7 in x 0.97 in x 0.97 in (42 mm x 24.6 mm x 24.6 mm)
Operating Environment-40 °C to +80 °C (-40 °F to +176 °F), 0 %RH to 100 %RH (non-condensing)
Required Interface PackageIFC400 or IFC406
ApprovalsCE

Temperature

Temperature SensorResistance Temperature Detector (RTD)
Temperature Range-40 °C to +80 °C (-40 °F to +176 °F)
Temperature Resolution0.01 °C (0.018 °F)
Temperature Response
Time in Air
t63 - 8 minutes to 63% of change
t90 - 68 minutes to 90% of change
Temperature Calibrated Accuracy±0.5 °C (0 °C to +55 °C)

Humidity

Humidity SensorCapacitive Polymer
Humidity Range0 %RH to 100 %RH (non-condensing)
Humidity Resolution0.1 %RH
Humidity Response
Time in Air
t90 - 2 minutes to 90% of change
Humidity Calibrated Accuracy±3 %RH maximum
Humidity Specified Accuracy Range25 %RH to 75 %RH
+20 °C to +40 °C
Hysteresis Error 1 % Typical, 3% Maximum.

Literature

RHTemp1000 Data Sheet

RHTemp1000 Product User Guide

Add-Ons

Part Numbers

RHTemp1000 — 901469-00
